Replaces art. no. 521320000, 521323000, 521423000
| Art. no. | 151.122.21.1 |
| Colour / surface | chrome / glossy |
| d, ø | 50–56 mm |
Geberit concealed trap for washbasin, with in-wall cabinet, ready-to-fit set, screen valve and overflow pipe, horizontal outlet
My list (0)
Technical data
Depth of water seal (mm) 50 mm |
Product material Plastic |
Depth of water seal (mm) 50 mm |
Product material Plastic |
Application purposes
Click on an application purpose to search more products
Characteristics
Click on a characteristic to search more products
Scope of delivery
Connection bend, ø 32 mm
Cover plate
In-wall cabinet
Concealed trap
Protection box
Valve screen
Overflow pipe for Renova Comfort washbasin
Overflow pipe for Vitalis washbasin
Fastening material
Seals
Documents
| Document type | Documents | Language | |
|---|---|---|---|
Installation instructions | WB concealed trap | - |
WB concealed trap
Other products
Spare parts
| # | Art. no. | Description | Replacement for |
|---|---|---|---|
| 1 | 240.648.00.1 | Geberit waste outlet with overflow pipe, for washbasin: G=1 1/4″, transparent | 00029100017, 521320000, 598108000 |
| 1.1 | 352.348.00.1 | Geberit overflow pipe made of plastic: transparent | |
| 4 | 240.649.21.1 | Geberit extension for washbasin connector: d=32mm, chrome / glossy | 131.080.00.1 |
