Additional information
- Actuator plate has to be ordered separately
My list (0)
Flow pressure 0.1–10 bar |
Flush volume, factory setting 4.5 / 3 l |
Flush volume large, adjustment range 4 / 4.5 / 6 / 7.5 l |
Flush volume small, adjustment range 2–4 l |
Product material Plastic |
Water supply connection R 1/2", compatible with MasterFix and MeplaFix, with integrated angle stop valve and hand wheel
Protection box for service opening
Flush bend with recess shells
Flush bend extension, ø 45 mm
Protection plug
2 slotted flat irons
Fastening material
Your input does not return any results
# | Art. no. | Description | Replacement for |
---|---|---|---|
1 | 242.414.00.1 | Geberit angle stop valve for Sigma concealed cistern 8 cm | |
1 | 246.175.00.1 | Geberit angle stop valve for Sigma/Delta concealed cistern 12 cm and Sigma/Alpha concealed cistern 8 cm | |
1.1 | 240.298.00.1 | Geberit spindle for angle valve with handwheel, left thread | |
32 Articles
